EV Power e-pood

Rated Power 2 x 22kW
Charging Connector Dual Type 2 Connector / Dual Type 2 Socket
Input Voltage & Current P+N+PE; 220V± 15%;16A 3P+N+PE; 380V± 15%;16A 3P+N+PE; 380V± 15%;32A
Working Frequency 50 / 60 Hz
Electrical Protection Over & Under Current,Voltage,Temperature Protection; Ground & Leakage Protection
Charging Authentication Plug and Play (default) / MONTA App and RFID (default ) / POS Machine (optional)
Display Screen 4.3" Touch Screen for Control Menu ; 32'' Non-Touch Screen for Advertisement Display
System Language Chinese / English / French / German / Spanish / Russian, etc.
Network Connection WiFi (default) / Ethernet + 4G (optional)
Communication Protocol OCPP1.6J
Operating Temperature -20°C ~ +60°C
Operating Humidity 5%~95%
Protection Grade IP65
Packing Dimension (WxDxH) 650mm * 350mm * 1750mm
Gross Weight About 90 kg
External Packing Wooden Box
Installation Floor-mounted
Certification & Reports CE, TUV, EMC, LVD
Design Standards EN IEC 61851，EN 62196
Warranty 2 Years
Shell Material Metal + UV Spray ; Color : Black / White
